Vein Finder

M892 Vein Finder

Brand: Medshine
Model No.: M892
Certificate: CE,ISO
Warranty:12 months
Product description: Vein Finder System is mainly applied by the medical staff for observing and locating patient’s subcutaneous vein in hospitals and clinics.
INQUIRY

M892 Vein Finder

Description

The Vein Showing System digitally displays a map of the vasculature on the surface of the skin in real time. Incorporate vein visualization technology as a routine strategy for difficult or poor venous access. Visualization technology can improve success rates, decrease unsuccessful insertion attempts. Vein visualization is proven technology.Thousands of hospitals around the world have implemented it and many have now adopted it as their standard of care.Succinct design will bring users a real brilliant experience.

Specification

Net weight of main engine	0.5 KG
Light source type	Near infrared
Projection Size	Large, Medium, Small, Very Small
Projection Color	Grey white, green, green background, red, blue, blue background
Projection Brightness	4 levels adjustable
Image size	854*480 pixels
Projection luminance	5-10 lumens
Optimum projection distance	23cm±3cm
Wave Length	850nm
Maximum Detection Depth	≤8mm
Power Supply	lithium battery
Power supply duration	Internal 7.2V 2200mAh,charging time≤3h, working time ≥4h
Hand-held	YES
Working angle	Multi-angle
Host size	220mm65mm65mm
