Vein Finder
M893 Vein Finder
- Brand: Medshine
- Model No.: M892
- Certificate: CE,ISO
- Warranty:12 months
- Product description: Vein Finder System is mainly applied by the medical staff for observing and locating patient’s subcutaneous vein in hospitals and clinics.
M893 Vein Finder
Description
The Vein Showing System digitally displays a map of the vasculature on the surface of the skin in real time. Incorporate vein visualization technology as a routine strategy for difficult or poor venous access. Visualization technology can improve success rates, decrease unsuccessful insertion attempts. Vein visualization is proven technology.Thousands of hospitals around the world have implemented it and many have now adopted it as their standard of care.Succinct design will bring users a real brilliant experience.
Specification
Net weight of main engine |
0.5 KG |
Light source type |
Near infrared |
Peak wavelength |
850Q±15nm 940±15nm |
ionizing radiation |
NO |
Projection accuracy |
≤0.3mm |
Image size |
640*480 pixel |
Projection luminance |
5-10 lumens |
Optimum projection distance |
23cm±3cm |
Image display mode |
4*4*3 |
depth information |
Pseudo-color 3D Technology |
Power Supply |
lithium battery |
Power supply duration |
4.5 H |
Hand-held |
YES |
Working angle |
Multi-angle |
Host size |
23.5*6.6*7cm |
