M221T Double Head Ultrasounder Probe Type Wireless Convex Transvaginal Scanner

Double Head Ultrasounder Probe Type

Wireless Convex + Transvaginal Scanner

Product introduction

The wireless probe is a mini ultrasound scanner without a screen. We minimize the components of a traditional ultrasound into a small circuit board built into the probe, and showing image in smart phone/tablet through Wifi transferring. Rotate built-in screen probe is a wireless ultrasound probe add screen, image can both show in screen and tablet. Image transferring through internal wifi from probe, no need external Wifi signal.

Features

* Workable with Tablet PC or Smart Phone (iOS, Android, Windows)

* Advanced digital imaging technology, clear image

* High cost-effective

* Wireless connectivity without probe cable, easy to operate, working freely

* Small and light , easy to carry

* Applicable in hospital, emergency, clinic, outdoor and vet inspection

* Intelligent terminal platform, powerful expansion functions on application, storage

* Waterproof design, convenient for sterilization

* Remote diagnostic convenience, capability and easy image transfer

Specifications

* Probe Head: R60 Convex+R13 Transvaginal

* Scanning mode: Electronic array

* Display mode: B, B/M, color doppler version with B+Color, B+PDI, B+PW

* Probe element: 128

* Channel of RF circuit board: 32

* Probe frequency and scan depth, head radius/width, scan angle(convex):

Convex head 3.2MHz/5MHz, 90/160/220/305mm, 60mm, 60°;

Transvaginal head 6MHz/8MHz, 30/60/90/120mm, 13mm, 149°

* Image Adjust: B Gain, TGC, DYN, Focus, Depth, Harmonic, Denoise, Color Gain, Steer, PRF

* Noise reduction: 0-1-2-3-4

* Cine play: auto and manual, frames can set as 100/200/500/1000

* Puncture assist function: the function of in-plane puncture guide line, out-of-plane puncture guide line, automatic blood vessel measurement.

* Gain: 30db-105db

* Dynamic Range: 40/50/60/70/80/90/100/110

* Image/Video Storage: Store on mobile phones, Tablet PC

* Measure: distance, area, obstetrics and other

* Power: by built-in lithium battery, 4200mAh

* Battery working time: 3 hours

* Size: 156mm×60mm×20mm

* Net Weight: 220 g
