Color Ultrasound

M221 3 in 1 Wireless Double Head Ultrasound Sonography

M221 3 in 1 Wireless Double Head Ultrasound Sonography

Brand: Medshine
Model No.: M221
Certificate: CE,ISO
Warranty:18 months
Product description: M221 is new designed ultrasound probe can both use WIFI and USB,can use wireless charging board to charge very convenient and portable carry,can realized Convex+Linear+Cardiac scan.
INQUIRY

M221 3 IN 1 USB/Wifi Type Color Ultrasound Scanner

Innovate

1. dual head , convex and cardia , linear scan

2. smaller than other probes, net weight is 90g

3. wifi and USB two connection

4. color doppler

Application

M221 is new designed ultrasound probe can both use WIFI and USB,can use wireless charging board to charge very convenient and portable carry,can realized Convex+Linear+Cardiac scan.

Features:

· Dual heads 3 in 1 ultrasound probe, the linear transducer is separate.

· Compatible with USB and wireless ports, making option diversify.

· It does not affect the use when charging and also can be charged by wireless charging.

· Only about 90 grams, it is lighter and smaller than ordinary probes.

· Software free download, free usage, free update

· More cost-effective with high quality imaging

Specification

Type	Linear+Convex+Cardiac, dual heads 3 in 1 probe
Frequency	Convex:3.5/5MHz Linear:7.5/10MHz Cardiac:2.5/5MHz
Depth	Convex:90~305mm Linear:20~100mm Cardiac:90~160mm
Elements	128
Package size	240(h)x235(w)x100(d)mm
Net weight	90g
Gross weight	1.5KGS
Wifi type	802.11n/20MHz/5G
APP interface	GN(gain)30-105
Battery Life	5~8years
Voltage	3.8V
Replaceable	No
Lithium Battery	2800mAh
Standby	3~5h
Bootup	Platformdependent, generally<5second
Adjustment	D(depth) ENH(enhancement)0-4 DR(dynamicrange)40-110 F(frequency) Mode B,B+M,B+Color,B+PW,B+PDI 8TGC
Application	Convex part:Abdominal, Emergency, Cardiac, Obstetrics/Gynecology, Lung, Kidney, Urology Linear part:Breast, Thyroid, MSK, Superficial, Vascular, Pediatrics, Carotid, SmallPart Cardiac part:Heart
Software	Android/Windows/IOS Download for free
Language	English, French, Spanish, Italian, Portuguese (Ipad)
