Syringe Pump

M642 Double Channel Syringe Pump

Brand: Medshine
Model No.: M642
Certificate: CE,ISO
Warranty:18 months
Product description: double channel syringe pump is our basic two channels syringe pump.Two syringe pumps allows injection with different flow rates and two colors design make it easy to distinct.
INQUIRY

M642 Double Channel Syringe Pump

Features of Dual Channel Syringe Pump

1. HD LCD Display, high capacity words, friendly user interface, dynamically display working status;

2. Visual alarm for occlusion, empty, near empty, low battery, end of infusion, syringe loose, wrong setting, etc.;

3.The syringe pump can be operated separately and compatible with 5ml, 10ml, 20ml, 30ml, 50/60ml syringe of any brands;

4. Preset solution volume to greatly reduce the workload of nurses;

5. Three working modes: Rate Amode, Time Volume mode, Dosage Weight mode;

6. Three levels of occlusion: high, medium and low;

7. Purge and Bolus function;

8.KVO(keep-vein-open) automatically opens as injection is completed, KVO rate is 1ml/h;

9. Power Source: AC100---240V, 50/60Hz; Internal Battery, DC12V car charge;

10. One-key operation makes setup easy and simple;

11. Syringe plunger grabble detector, operable with one hand in a No-Germ Environment;

12. Automatically record the settings of last injection;

13. OEM is available.

Specification of Dual Channel Syringe Pump

Rate	50/60ml Syringe: 0.1ml/h ~ 999.9ml/h (0.1ml/h step) 1,000ml/h ~ 1,500ml/h (1ml/h step) 30ml Syringe: 0.1ml/h ~ 900.0ml/h (0.1ml/h step) 20ml Syringe: 0.1ml/h ~ 600.0ml/h (0.1ml/h step) 10ml Syringe: 0.1ml/h ~ 300.0ml/h (0.1ml/h step)
Flow Rate Accuracy	Within ±3% (after correct calibration)
Mechanical precision	Within ±2%
Bolus Rate	50/60ml Syringe: 1,200ml/h 30 ml Syringe: 720ml/h 20 ml Syringe: 480ml/h 10 ml Syringe: 240ml/h
Purge Rate	50/60ml Syringe: 1,500ml/h 30ml Syringe: 900ml/h 20ml Syringe: 600ml/h 10ml Syringe: 300ml/h
Volume Limit	0.1ml ~ 9999.9ml(0.1ml step)
Total Injection Volume	0.1ml ~ 9999.9ml (0.1ml step)
Occlusion of Dual Channel Syringe Pump	High: 800mmHg ±200mmHg (106.7kPa±26.7kPa Medium: 50/600mmHg ±100mmHg (66.7kPa±13.3kPa Low: 300mmHg ±100mmHg (40.7kPa±13.3kPa )
Alarms	Injection soon finish, end of injection,occlusion, improperly installation of syringe, wrong setting, low battery, syringe loose etc.
Power Source	AC 100V ~ 240V, 50/60Hz; Internal rechargeable Li battery, capacity≥1,600mAh, 4 hours internal battery backup
KVO rate	1ml/h
Fuse	F1AL/250/60V, 2pcs inside
Power Consumption	30VA
IP Classification	IPX4
Equipment Classification	Class II, internal power supply, Type CF
Operating Condition	Ambient temperature: +5℃~ +40℃
Relative humidity	20 ~ 90%
Transport & Storage Condition	Ambient temperature:-30℃~ +55℃
Relative humidity	≤95%
Dimension	280mm (L) ×210mm(W) ×130mm(H)
Weight	3.6kg (net weight)
